Solar PowerHUB PLUS
Our Most Powerful Unit Yet!
Introducing the PowerHub Plus.
New PowerHub Plus Specifications
|
Inverter Specifications
|
|
Maximum power
|
1800 W
|
|
Continuous power
|
1440 W
|
|
Surge rating
|
2880 W
|
|
Output current (continuous)
|
12.0 A
|
|
Output voltage
|
115 Vac +/- 10 Vac
|
|
Output frequency
|
60 Hz +/- 1 Hz
|
|
Output waveform
|
Modified sine wave
|
|
Peak efficiency
|
88%
|
|
No-load battery power draw
|
<12 W
|
|
No-load battery power draw (unit off)
|
< 3 W
|
|
Input operating voltage range
|
< 10.5 to 15.0 Vdc
|
|
Fuse (resettable):
|
|
|
AC outlet
|
15 A breaker
|
|
Fuse (user replaceable):
|
|
|
Battery box
|
10 x 20 A
|
|
Transfer time
|
< 40 milliseconds
|
|
Operating temperature range
|
32°F to 104°F (0°C to 40°C)
|
|
Storage temperature range
|
-4°F to 140°F (-20°C to 60°C)
|
|
AC receptacles
|
4
|
|
AC hardwire terminal block
|
15 A max
|
|
|
Battery Charger Specifications
|
|
Output current
|
0/10/40 A
|
|
Output voltage
|
|
|
Charge
|
14.2 Vdc
|
|
Float
|
13.7 Vdc
|
|
Recharge
|
12.5 Vdc
|
|
AC input voltage
|
115 Vac 50/60 Hz
|
|
Charger efficiency
|
80% approximate
|
|
Charging type
|
Three-stage
|
|
Charge time
|
64 hours
|
|
Solar Panels
|
|
Type
|
Silicon Mono-Crystal (x4)
|
|
Maximum Output Power
|
150 W + 3% each
|
|
Maximum Power Voltage
|
29.8 V
|
|
Maximum Power Current
|
5.04 A
|
|
Open Circuit Voltage
|
36.2 V
|
|
Short Circuit Current
|
5.54 A each
|
|
Maximum System Voltage
|
1000VDC
|
|
Charge Time
|
16 hours (typical with 4 batteries)* [With ideal panel orientation and sunshine conditions]
|
|
Temperature Range
|
-40°F to 140°F (-40°C to 60°C)
|
|
|
Physical Specifications
|
|
Inverter dimensions (H x W x D)
|
14.1 x 8.0 x 16.1” (35.8 x 20.3 x 41 cm)
|
|
Battery box dimensions
|
13.9 x 13.9 x 20” (35.2 x 35.2 x 50.8 cm)
|
|
Inverter & 2 battery box dimensions
|
35.6 x 20.3 x 18.25” (35.8 x 55.6 x 50.8 cm)
|
|
Weight inverter
|
27.3 lb (12.4 kg)
|
|
Weight battery box
|
29.0 lb (13.15 kg)
|
|
Weight Two Battery Boxes with Cart Batteries and Inverter
|
420.0 lb (924 kg)
|
|
Solar Panel Dimensions
|
52 x 32 x 2″ (132.1 x 81.3 x 5.1 cm)
|
|
Solar Panel Weight
|
75 lbs each (x4)
|
|
Warranty
|
90 Day Warranty
(Extended warranty
can be purchased.)
20 Years On Solar Panel |
|
|
DC Section (Batteries X 2
|
|
Included Battery Box Capacity
|
4 group 27 size batteries
|
|
Included Battery Type
|
Sealed lead-acid, Deep cycle
|
|
Included Battery Capacity
|
100 Ah x 4
|
|
Included Battery Voltage
|
12 Vdc (nominal)
|
|
Solar Controller x 2
|
|
System Voltage
|
12/24 V
|
|
Maximum PV Input
|
75V
|
|
Rated PV Input
|
200 W/ 400 W
|
|
Rated Load
|
15 A
|
|
Control Type
|
MPPT x 2
|
|
Temperature Range
|
-40°F to 140°F (-40°C to 60°C)
|
|
